1 TNX-002
| ParameterL | Specifications | Description |
|---|---|---|
| · Model | TNX-002 | |
| · Frequency | 1565-1610 MHz (L1) | GPS L1 GLONASS L1 GALILEO E1 BDS B1 OZSS L1 SBAS L1 |
| · Polarization | RHCP | |
| · Passive peak gain | 1.5 dBi / 1575 MHz (typical) | |
| · Total gain | 30 cBi / 1575 MHz (typical) | |
| · Current drain | 5 8mA (typical) : 민수용 | ≤15 mA (typical) : 군용 |
| · Voltage | 3-14 V | |
| · Noise figure | 1.5 dB (typical) | |
| · RF interference rating | 50 V/m Jamming resistant | |
| · Connector | SMA Male | |
| · Operating temp | from -40°C to 85°C | |
| · Ingress Protection | IP67 (Water Resistant) | |
| · Axial Ratio | 0.5 dB (typical) / 1 dB (max) | |
| · VSWR | ≤1.5 | |
| · W.D.H |
